Foaming devices

FOAM-MATIC 5 P Foaming Device

Thanks to the large pressure accumulator volume and hand pump, foaming is quick and mobile regardless of the compressed air connection.

  • Break-resistant and robust plastic container with a 5 litre
    capacity, 2.5 l pressure pad and 4 bar pressure accumulator / operating pressure
  • Pressure pad and 4 bar pressure accumulator / operating pressure
  • Especially short foam tube
  • 50 cm foam tube extension (optional)
  • High-quality and powerful hand pump with two hand grip
  • Version with stainless steel piston rod and sleeve guide
  • Integrated pneumatic valve
  • Chemically resistant Viton seals
  • Pressure relief valve
  • Reinforced 1.5 m pressure hose attached to the container head
  • Large filling opening with integrated funnel

Optional: Extension set 50 cm long, bent stainless steel tube with connections and seals.

INDU-MATIC 20 M Foaming Device

Mobile stainless steel foaming device, ideal for the foaming of cavities contaminated with mould, spores or bacteria. Approx. 800 litres of foam can be produced with one charge.

  • Stainless steel container, 20 litre filling volume
  • Large filling opening with a quick-release closure
  • Robust mixing unit for an adjustable foam quality from liquid to dry
  • Pressure regulating valve and compressed air connection with a quick-release coupling
  • Robust manual valve with integrated filter screen
  • Handy 45 cm spray pipe tube made of stainless steel
  • 4 m hose line for a large radius of use
  • Can be converted from foaming to spraying
  • Chemically resistant Viton seals
  • Pressure relief valve – also for rapid venting
  • Pressure gauge
  • CE and TÜV-approved

Technical data

Material: stainless steel
Seals: Viton
Hose line: PVC, 4 m
Manual valve: plastic/stainless steel
Nozzle type: flat jet nozzle
Tare weight: 6.5 kg
Dimensions: height 89 cm, diameter 21 cm
Container volume: 23.5 litres
Maximum capacity: 20 litres
Maximum operating pressure: 6 bar
Optimum operating pressure: 4 – 5.5 bar
Operating temperature: 5 – 50°C

INDU-MATIC 50 M Foaming Device

Mobile stainless steel foaming device, ideal for the foaming of cavities contaminated with mould, spores or bacteria. Approx. 2000 litres of foam can be produced with one charge.

  • Stainless steel container, 50 litre filling volume
  • Large filling opening with a quick-release closure
  • Robust mixing unit for an adjustable foam quality from liquid to dry
  • Pressure regulating valve and compressed air connection with a quick-release coupling
  • Robust manual valve with integrated filter screen
  • Handy 45 cm spray pipe tube made of stainless steel
  • 6 m hose line for a large radius of use
  • Can be converted from foaming to spraying
  • Inc. stainless steel trolley
  • Pressure relief valve – also for rapid venting
  • Pressure gauge
  • CE and TÜV-approved

Technical data

Material: stainless steel
Seals: Viton
Hose line: PVC, 6 m
Manual valve: plastic/stainless steel
Nozzle type: flat jet nozzle
Tare weight: 14 kg
Dimensions: height 52 cm, diameter 41 cm
Container volume: 50 litres
Maximum capacity: 45 litres
Maximum operating pressure: 6 bar
Optimum operating pressure: 4 – 5.5 bar
Operating temperature: 5 – 50°C

JATI Cavity Hose

The JATI Cavity Hose was developed to insert JATI 2KDS Cavity Foam System into cavities (such as sprung floors, raised floors, shafts and other hard-to-reach areas).

The special hose is characterised by flexibility as well as dimensional stability and is ideal for use in floor areas.

The hose is multi-layered. The inner hose with a diameter of 20 mm ensures the safe transport of the foam over the entire hose length of 1, 3 or 5 metres due to the structure of the surface. The fibreglass rod fixed to the hose provides stability as well as good flexibility. This allows for good and easy positioning in the cavity area. The outer rubber cable overlay hose with a textile coating serves as a safeguard against wear from abrasion on the floor.
The ball valve on the hose is connected with a GK safety hose coupling. If several hoses are being used at the same time, it is possible to switch easily and safely to the foaming device being used. The ball valve is used for easy dosage of the foam. Available in lengths of 1 m, 3 m or 5 m.
